    Rural weBoost Office 200 Cell Signal Booster 50 Ohm | Top Signal Series

    Call us for discounted pricing! (435) 634-6800
    Bulk Pricing:
    Buy in bulk and save

    Tier Price Rates

    • The power of a commercial booster for rural homes and small offices
    • High-gain directional outside antenna for better reception in remote areas
    • Your choice of 1–4 inside low-profile dome or flex-mount EDGE panel antennas
    • LCD touchscreen controls
    • Boosts voice & 5G/4G data for all major cellular carriers
    • 50-ohm system with N connectors & low-loss 400 coax cable
    Outside Signal Strength
    Coverage @ 700 MHz LTE
    5 Bars
    Up to 33,000 ft²
    3 Bars
    Up to 20,000 ft²
    1 Bar
    Up to 4,000 ft²

    Free lifetime support
    $1,949.99
    SKU: 472047-HG1
    Shipping:
    Calculated at Checkout

    Product Description

    Call the experts at Powerful Signal for cell signal booster product information and lifetime support
    Call the experts at Powerful Signal for cell signal booster product information and lifetime support
    Need professional installation? Check out the weBoost Office 300 Installed.

    Features of the Rural weBoost Office 200 signal booster

    • Designed for large homes and small offices 8 to 10 miles or more from a cell tower and with a reasonable line of sight to the tower.
    • This system includes over $300 in bonus components that improve performance in rural areas:
    • The high-gain directional antenna with rooftop mount provides stronger signal to the amplifier, increasing your indoor coverage area by 10 percent or more over the standard antenna.
    • Your choice of 1 to 4 ceiling-mounted Wilson low-profile dome antennas or wall-mounted Top Signal EDGE dome antennas.
    • Coverage for large homes, small offices and retail businesses, and other buildings up to 4,000 square feet (with weak outside signal strength).
    • Ample uplink power (24–25 dBm) for a stronger connection to the cell tower and better performance in areas with weak outside cellular signal.
    • Color LCD touchscreen displays the status and gain of each cellular band and allows you adjust the amplifier’s settings.
    • Wall-mounted amplifier with antenna ports on the top and a compact size (9″ ᴡ × 10″ ʜ × 2″ ᴅ).
    • Boosts 5G and 4G/LTE service for voice, text, and data for all major U.S. cellular carriers.
    • Three-year manufacturer’s warranty on the booster.
    weBoost Office 200 LCD display The weBoost Office 200’s touchscreen LCD color display provides greater control and usability.

    The Rural weBoost Office 200 is a wall-mounted commercial amplifier specially bundled for large homes and small offices that have weak outside cellular signal.

    This rural kit, available only from Powerful Signal, includes your choice of one to four Wilson Electronics low-profile dome antennas or Top Signal EDGE panel antennas, an outdoor high-gain wideband antenna with an average of 6½ times the gain (+8.1 dB) of Wilson’s standard omni antenna, and an 18″ reversible rooftop mount for the outside antenna.

    Upgrade option: Need more power or coverage? Get it here! Customers also like: Learn more about antenna and coverage options

    Who is the Rural weBoost Office 200 for?

    • Large homes, custom homes, and small offices in remote locations with weak cell service (rural areas, farms, cabins, new developments, etc.).
    • Large homes and small offices 8 to 10 miles or more from a cell tower.
    • Homes with basements, theater rooms, metal out-buildings, and other places where cell reception is poor.

    Get installation help with the weBoost smartphone app

    The weBoost app measures signal performance, pinpoints the nearest cell tower, and shows your cell signal strength before and after installation. It includes step-by-step setup instructions and how-to videos for weBoost products.

    The weBoost app for iPhone and Android smartphones for use with weBoost cell signal boosters

    Purchasing a Rural weBoost Office 200

    The weBoost Office 200 can be self-installed if you are familiar with cellular amplification equipment. We’ll be happy to advise you on the best placement of antennas or provide a custom, turnkey solution. If you purchase this system as a standalone product, it includes the following components:

    The one-antenna kit includes:

    weBoost Office 200 50-ohm booster 472047 icon weBoost Office 200 50-ohm cell signal amplifier
    weBoost Office 300 120V AC/DC power supply 850026 icon 12V/3A AC/DC wall outlet power supply w/locking plug 850026
    Outdoor High-Gain Directional LPDA Antenna with N-Female Connector (50 Ohm) and U-Bolts icon UPGRADED
    Top Signal wideband high-gain LPDA antenna w/mounting hardware TS221101
    Wilson Indoor Ceiling-Mount Omnidirectional Low-Profile Antenna with N-Female Connector (50 Ohm) 314407 icon Choice of…
    Wilson wideband low-profile dome antenna w/mounting hardware 314407
    Top Signal EDGE Flex-Mount Panel Antenna N-Female TS260820 icon …or
    Top Signal EDGE indoor panel antenna w/mounting hardware TS260820
    WILSON400 coax 75 ft. N-Male Connectors 952375 icon 75′ WILSON400 coax cable w/N-male connectors 952375
    WILSON400 coax 60 ft. N-Male Connectors 952360 icon 60′ WILSON400 coax cable w/N-male connectors 952360
    WILSON400 coax 2 ft. N-Male Connectors 952302 icon 2′ WILSON400 coax jumper cable w/N-male connectors 952302
    Wilson 859902 Lightning Surge Protector 50 Ohm N-Female/N-Female icon Wilson 50-ohm lightning surge protector 859902
    BONUS
    Adjustable rooftop antenna mount TS430001
    weBoost Office 200 471047 installation guide icon weBoost Office 200 install guide

    The multi-antenna kits add:

    Wilson Indoor Ceiling-Mount Omnidirectional Low-Profile Antenna with N-Female Connector (50 Ohm) 314407 icon Choice of…
    Wilson wideband low-profile dome antenna w/mounting hardware 314407 (×2–4)
    Top Signal EDGE Flex-Mount Panel Antenna N-Female TS260820 icon …or
    Top Signal EDGE indoor panel antenna w/mounting hardware TS260820 (×2–4)
    Top Signal 400 coax 75 ft. N-Male Connectors TS340075 icon 75′ Top Signal TS-400 coax cable TS340075 (×1–3)
    Top Signal 400 coax 2 ft. N-Male Connectors TS340002 icon 2′ Top Signal TS-400 coax jumper cable TS340002
    Top Signal TS412101 2-Way TS413101 3-Way TS414101 4-Way Splitters 50 Ohm N-Female icon Top Signal 2-, 3-, or 4-way 50-ohm splitter TS41x101*

    * This system ships with the appropriate splitter for the number of indoor antennas. One-antenna systems do not include a splitter.

    Optional plenum air coax cable upgrade

    The weBoost Office 200 system includes a 400-type coax cable to connect the amplifier to the inside antenna. If your small office requires fire-rated cableexternal link icon in plenum spaces, please ask us about upgrading to ½-inch plenum air coax. Plenum cable fully meets state and federal building codes.

    Plenum cable also has nearly half the signal loss per foot of cable compared to 400-type coax cable, delivering stronger signal from the weBoost amplifier to your phones and other cellular devices.

    (Plenum air cable is available at additional cost. Call Powerful Signal at 435-634-6800 for details.)

    400-type coax cable and plenum air coax cable terminated with N-male connectors This system uses 400 coax (left), but you can upgrade to fire-rated plenum air coax cable (right) for building-code compliance and better performance.

    How the weBoost Office 200 works

    The weBoost Office 200 receives available outside cell signal, amplifies it, and rebroadcasts it inside your home or small office. This allows you to stay connected in areas where indoor cell service is poor because excessive distance to the cell tower.

    Works with all major cellular carriers

    The weBoost Office 200 works with all major wireless carriers, including Verizon, AT&T, T-Mobile, DISH Wireless, UScellular, GCI Alaska, and most others.

    It operates on common cellular frequencies.

    • 700 MHz (SMH) bands 12, 13, 17.
    • 850 MHz (Cellular 850) band 5.
    • 1700/2100 MHz (AWS) band 4.
    • 1900 MHz (PCS) bands 2, 25.
    Carrier logos for Verizon, AT&T, T-Mobile, UScellular, DISH Wireless, GCI Alaska
    T-Mobile customers please read about band 71 and cell signal boosters

    Which inside antenna should I choose?

    This system gives you the choice of an indoor ultra-thin dome or flex-mount panel antenna. Here are some general guidelines for selecting the right antenna.

    Inside (broadcast) antenna:

    • The ceiling-mounted ultra-thin dome antenna broadcasts downward and all around in a shape similar to a donut or an inner tube. It usually gives more broad, even coverage than a wall-mounted panel antenna and is less noticeable than a panel antenna. Installing a dome antenna does, however, require that you have access above the ceiling to pull cable and mount the antenna. It also requires sufficient vertical separation between the outside directional antenna and the inside dome antennas to prevent signal oscillation.
    • The wall-mounted panel antenna broadcasts forward in a sideways teardrop shape. It’s a better option if you don’t have access above your ceiling, if you want to mount the antenna on the outside perimeter of the area you want to cover, or for covering long, narrow indoor areas. Because you can point it away from the outside directional antenna, it’s also the better choice if you can’t get enough vertical separation between the antennas to prevent the booster from oscillating.

    If you’re still not certain which antennas will work best for you, please call us at 435-634-6800. Our technical support representatives will be happy to discuss your specific requirements and give you a recommendation based on years of professional experience.

    How much area will the weBoost Office 200 cover?

    The coverage area this system can provide depends on many factors, including:

    • Outside signal strength received by the outside donor antenna.
    • Where you mount the inside antenna(s).
    • Inside building materials. (Cellular frequencies pass through wood framing and drywall more easily than through steel and concrete.)
    • The cellular frequencies used by the carrier. (Lower-frequency SMH and CLR signals travel farther than higher-frequency AWS and PCS signals.)

    In general, the stronger the outside cell signal, the greater the interior broadcast distance.

    Powerful Signal has has been designing and installing cellular amplification systems since 2007. Please call us at 435-634-6800 or contact us online, and we’ll be happy to calculate the coverage area this system will provide in your building and answer any other questions about this amplifier.

    FCC notice

    For information on federal rules governing the use of consumer cell signal boosters, please see our FCC notice page.

    Prop 65 notice

    Caution triangle icon Warning This product can expose you to chemicals, including nickel, which is known to the State of California to cause cancer, and Bisphenol A, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.govexternal link icon.

    Product Specifications

    Usage:
    Large homes & small offices
    Strong outside signal (−95 dBm RSRP, 5 bars):
    Up to 33,000 ft² indoor coverage @ 700 MHz
    Fair outside signal (−105 dBm RSRP, 3 bars):
    Up to 20,000 ft² indoor coverage @ 700 MHz
    Weak outside signal (−115 dBm RSRP, 1 bar):
    Up to 4,000 ft² indoor coverage @ 700 MHz
    Outside Antenna:
    High-gain directional LPDA
    Inside Antenna:
    Omnidirectional dome or directional panel (×1–4)
    Cable Type:
    400
    Connector Type:
    N
    Impedance:
    50 Ω
    Gain/Loss:
    +72 dB max
    Max Output Power (Uplink):
    25.0 dBm
    Max Output Power (Downlink):
    15.3 dBm
    Booster Case Material:
    Metal
    Signal Readout:
    LCD display with output signal in dBm

    Warranty Information

    For warranty information on this product, please see our WilsonPro warranty information page.
