Top Signal Pole-Mount 700 MHz 10 dBi Yagi Antenna N-Female TS231072

Top Signal Pole-Mount 700 MHz 10 dBi Yagi Antenna N-Female TS231072

High gain 700 MHz band antenna
  • For cellular bands 12, 13, and 17 (698–790 MHz)
  • 31½″ Yagi antenna for 50 Ohm systems
  • N-female connector
  • Attach to pole (TS430001, sold separately
  • U-bolt bracket (included)

$79.95
SKU: TS231072
Shipping:
Calculated at Checkout

Product Description

Features of the Top Signal 10 dBi Yagi antenna

  • 31.5 × 8.25‑inch directional Yagi building antenna.
  • Mounts upright on tower or pole 1.2–2.3 inches in diameter with U‑bolts (mounting bracket included; pole sold separately).
  • N‑female connector with “pigtail” cable attachment.
  • 50‑ohm impedance.
  • +10 dBi gain.
  • Beamwidth: Horizontal plane 54°, vertical plane 45°.
  • Made from 6061-T6 all-weather anodized aluminum.
  • Works with cellular networks operating in the 698–790 MHz range (cellular bands 12, 13, and 17).
  • 90‑day warranty.

How the Top Signal 10 dBi Yagi works

  • Receives outside signal from a cell phone tower and directs it to a cell phone signal booster.
  • For use outside commercial buildings, offices, and homes.
  • Works with 50 Ohm cell signal booster systems, including WilsonPro, weBoost, HiBoost, and Top Signal kits.
  • Attaches to roof or side of building (clear of any obstructions) with a Top Signal TS430001 adjustable building antenna mount (sold separately).

Learn more about Yagi antennas in our blog post , “What’s the difference between an LPDA antenna and a Yagi antenna?

Top Signal 10 dBi Yagi antenna contents

Top Signal Pole-Mount 700 MHz 10 dBi Yagi Antenna N-Female TS231072 icon Wideband outdoor Yagi antenna TS231072
Top Signal TS231072/TS231472 antenna U-bolts and hardware icon Threaded U-bolts, nuts, and washers (×2)

Product Specifications

Usage:
Office/residential
4G/3G:
4G
Connector Type:
N-female
Cable Type:
RG-6
Cable Length:
15 in. (38 cm)
Antenna Type:
Outside directional Yagi
Antenna Length:
31.5 in. (80 cm)
Polarization:
Vertical
Mount Type:
U-bolt bracket
Mount Spec:
Attaches to 1.2–2.3 in. poles
Impedance:
50 Ω
Gain 698–790 MHz:
+10.0 dBi
Beamwidth Horizontal Plane:
54°
Beamwidth Vertical Plane:
45°

Warranty Information

For warranty information on this product, please see our Top Signal warranty information page.
