    Top Signal Folding 600–4000 MHz 5G OTR Cellular Vehicle Antenna SMA-Female TS210402

    FREE 180° fold-down swivel mount!
    Bulk Pricing:
    Buy in bulk and save

    Tier Price Rates

    • Outside antenna for trucks, RVs, fifth-wheels, trailers & class B adventure vans
    • Range of 600–4000 MHz 5G frequency
    • Mast extension & cable side-exit adapter for your choice of 11.25″, 19.5″, or 22.25″ antenna height
    • 10′ of flexible RG58 coax cable connects the 5G antenna to your cell phone signal booster
    • 3-way L-bracket mount attaches to rails or mirror brackets
    • FREE 180° fold-down swivel mount; 5 optional mounts also available

    Free lifetime support
    $99.99
    SKU: TS210402
    Shipping:
    Calculated at Checkout

    Product Description

    Features of the Top Signal Folding 5G OTR antenna

    • Omnidirectional antenna for trucks, commercial vehicles, RVs, fifth wheels, trailers, and class B vans.
    • Works with 600–4000 MHz 5G and 4G/LTE frequencies and provides 2.3–4.1 dBi of gain. (Learn more about 5G compatibility.)
    • Includes a mast extension and side-exit adapter for your choice of 11.25″, 19.5″, or 22.25″ antenna height (28.5, 49.5, or 56.5 cm).
    • FREE chromed aluminum swivel mount fixable at any angle through 180° (horizontal–vertical–horizontal).
    • A 16″ (40.6 cm) pigtail cable exits the bottom of the mast or through the side-exit adapter. A 10′ (3.05 m) RG58 coax cable connects to the pigtail cable; its thin SMA-female connector threads through a 1⁄4″ (6.4 mm) opening into your vehicle.
    • An SMA-male barrel connector attaches to signal boosters with SMA-female connectors. (Need an adapter?)
    • The included 3-way L-bracket mount attaches to poles or rails. Five optional upgraded antenna mounts also available (see below).
    • Optional gumdrop/beehive CB antenna stud mounts to openings up to 1″ (2.5 cm) in diameter.
    • 2-year warranty.
    OTR antennas from Powerful Signal - RFI, Top Signal, Wilson See our complete comparison.

    Who is the Top Signal 5G OTR antenna for?

    • OTR truckers and drivers of other CMVs.
    • RVs, fifth wheels, trailers, and class B adventure vans.
    • Field service technicians (oil, gas, agriculture, etc.).
    • Government agencies (Forest Service, executive and legislative staff, military, etc.).
    • Emergency responders (police, sheriff, fire, EMT, etc.).
    • Delivery and service vans.

    Do-it-yourself installation

    Installing the Top Signal 5G OTR antenna is simple and fast. It does not require professional help; you can do it yourself in about 20 minutes.

    The antenna, the folding mount, or the optional quick-release mount can be installed in a 3⁄8″ × 24 CB mount. You can also attach the antenna to a rail with the included 3-way L-bracket, or install it with an optional S bracket, MagMAX magnet mount, MagMAX 3X magnet mount, or Rhino-Rack® folding bracket.

    You can download the installation instructions here.

    Download the Top Signal 5G OTR antenna TS210402 installation guide (PDF) Top Signal 5G OTR antenna installation guide. (Click to download.)

    Do you need an adapter?

    The Top Signal 5G OTR antenna has 11.3 feet of RG58 coax cable terminated with an SMA-female connector. The kit includes an SMA-male barrel adapter for connecting to cell signal boosters with SMA-female connectors.

    If your cell signal booster has SMA-female connectors, you do not need to adapt this antenna; it will connect to your booster natively. Boosters with SMA connectors include the weBoost Drive Reach (models manufactured since spring 2022), the HiBoost Travel 4G 2.0 and Travel 3.0, the Nextivity CEL-FI GO G32 Mobile, and the weBoost Drive X and Drive 4G-X.

    You will need to add an optional adapter (above) if you intend to use this antenna with any of the following boosters:

    Choose the adapter add-on option at the top of this page before clicking Add to Cart.

    FME-male FME-female SMA-male SMA-female SMB-male SMB-female N-male N-female connectors This comparison will help you identify the connectors on your booster and its coax cables. (Click to enlarge.)

    Top Signal 5G OTR antenna contents

    Top Signal 5G OTR Antenna TS210402 antenna with 16-inch RG58 feeder cable icon 8.5″ (21.5 cm) antenna enclosure w/16″ (40.6 cm) RG58 feeder cable, attached
    Top Signal 5G OTR Antenna TS210402 mast extension icon 11.1″ (28.1 cm) mast extension
    Top Signal 5G OTR Antenna TS210402 side exit adapter icon 2.75″ (7.0 cm) side-exit adapter
    Top Signal 5G OTR Antenna TS210402 hex nut, lock washer, flat washer icon Hex nut, lock washer & flat washer
    Top Signal 5G OTR Antenna TS210402 10-foot RG58 coax cable icon 10′ (3.05 m) RG58 coax cable w/SMA-male & SMA-female connectors
    Top Signal 5G OTR Antenna TS210402 SMA-male to SMA-male barrel connector icon SMA-male to SMA-male barrel connector
    Top Signal 5G OTR Antenna TS210402 3-way L-bracket mount icon L-bracket 3-way mount w/hardware
    Top Signal 180 Degree Folding Mount for Cellular Antennas TS431002 icon FREE BONUS
    Top Signal folding mount w/lock washer, nut & hex key TS431002
    Top Signal 5G OTR Antenna TS210402 installation guide icon Top Signal 5G OTR installation guide
    Top Signal Quick-Release CB Antenna Mount TS431003 icon Optional add-on
    Top Signal quick-release antenna mount TS431003
    Top Signal Stainless Steel S Brack TS432006 with Gumdrop/Beehive CB Antenna Mount TS431004 icon Optional add-on
    Top Signal stainless steel S bracket TS432006 w/gumdrop CB antenna mount TS431004
    Top Signal MagMAX OTR Trucker Magnetic Antenna Mount TS432010 icon Optional add-on
    Top Signal MagMAX antenna mount TS432010
    Top Signal MagMAX 3X OTR Trucker Magnetic Antenna Mount TS432011 with Gumdrop/Beehive CB Antenna Mount TS431004 icon Optional add-on
    Top Signal MagMAX 3X antenna mount TS432011 w/gumdrop CB antenna mount TS431004
    Rhino-Rack Folding Aerial Bracket 43196 icon Optional add-on
    Rhino-Rack folding aerial bracket 46196 w/3-way rail mount TS432120 & gumdrop CB antenna mount TS431004
    Top Signal SMA-Female to SMB-Female Connector TS451039 icon Optional add-on
    SMA-female to SMB-female connector TS451039
    Top Signal TS451036 FME-Female to SMA-Female Connector icon Optional add-on
    FME-female to SMA-female connector TS451036

    Please note

    • This antenna will not operate by itself; it is one component of a cell signal booster system. Please contact Powerful Signal—we’ll be happy to help you determine what your needs are and what system will work best in your situation.

    Product Specifications

    Usage:
    Commercial truck/RV/Fifth-wheel/Trailer/Class B Adventure Van
    Connector Type:
    SMA-female/SMA-male (w/adapter)
    Cable Type:
    RG58
    Cable Length:
    10.0′ (3.05 m)
    Antenna Type:
    Outside omnidirectional
    Antenna Length:
    11.25″, 19.5″, or 22.25″ (28.5, 49.5, or 56.5 cm), depending on setup
    Polarization:
    Vertical
    Mount Type:
    CB/3-way mount/fold-down mount
    Mount Spec:
    3⁄8-in. × 24 thread
    Impedance:
    50 Ω
    Gain 600–798 MHz:
    +3.3 dBi
    Gain 806–960 MHz:
    +3.2 dBi
    Gain 1710–1880 MHz:
    +4.1 dBi
    Gain 1990–2170 MHz:
    +3.9 dBi
    Gain 2300–2700 MHz:
    +3.4 dBi
    Gain 3300–4000 MHz:
    +2.3 dBi

    Warranty Information

    For warranty information on this product, please see our Top Signal warranty information page.
