Wilson 4G Low-Profile Dome Antenna N-Female 314407: Antenna

Wilson 4G Low-Profile Dome Antenna N-Female 314407

  • Indoor building antenna for 50 Ohm systems
  • “Pigtail” cable with N-female connector
  • Attaches to inside drop or drywall ceiling
  • Mounting nut included

SKU: 314407
Calculated at Checkout
Powerful Signal has been in business over 10 years Powerful Signal is Wilson Electronics' most experienced partner Powerful Signal offers lifetime support on all systems it sells Powerful Signal offers nationwide installation

Product Description

Features of the Wilson low-profile dome antenna

  • 9.4 × 9.4 × 0.33‑inch omnidirectional indoor building antenna.
  • Mounts to drywall ceiling or other drillable, horizonal surface no thicker than 1.5 inches (mounting nut included; ceiling access required for installation).
  • N‑female connector with “pigtail” cable attachment.
  • 50‑ohm impedance.
  • +4–6 dBi gain.
  • Beamwidth, 698–2700 MHz: 360° horizontal, 100–130° vertical.
  • Works best with 4G cell phone signal boosters.
  • 2‑year warranty.

How the Wilson low-profile dome antenna works

  • Receives inside signal from a cell phone signal booster and directs it to multiple cell phones inside the building.
  • For use inside commercial buildings, offices, and homes.
  • Works with 50‑ohm cell phone signal booster systems.
  • Optional above-ceiling radome increases gain +1–3 dBi (available as the Wilson 314406).

Wilson low-profile dome antenna contents

Wilson 4G Indoor Ceiling-Mount Omnidirectional Low-Profile Antenna with N-Female Connector (50 Ohm) 314407 icon Wideband low-profile dome antenna
Hardware for Wilson 4G Indoor Ceiling-Mount Omnidirectional Low-Profile Antenna with N-Female Connector (50 Ohm) 314407 icon Ceiling mount, nut, and tab ring

Please note

  • This antenna will not operate by itself; it is one component of a cell signal booster system. Please contact Powerful Signal—we’ll be happy to help you determine what your needs are and what system will work best in your situation.

Product Specifications

Connector Type:
Cable Type:
Cable Length:
10 in. (25 cm)
Antenna Type:
Inside omnidirectional
Antenna Diameter:
9.4 in. (23.9 cm)
Mount Type:
Nylon mounting nut
Mount Spec:
Attaches to drywall or other drillable surface
50 Ω
Gain 700–800 MHz:
+4 dBi
Gain 824–894 MHz:
+4 dBi
Gain 880–960 MHz:
+4 dBi
Gain 1710–1880 MHz:
+6 dBi
Gain 1850–1990 MHz:
+6 dBi
Gain 2110–2170 MHz:
+6 dBi
Beamwidth Horizontal Plane:
Beamwidth Vertical Plane:

Warranty Information

Wilson Electronics accessories are warranted for ninety (90) days against defects in workmanship and/or materials. Warranty cases may be resolved by returning the product directly to the reseller with a dated proof of purchase. See reseller warranty procedures.

This warranty does not apply to any accessories or components determined by Wilson Electronics to have been subjected to misuse, abuse, neglect, or mishandling that alters or damages physical or electronic properties.
