weBoost eqo 4G Cell Phone Signal Booster for Single Room 474120

weBoost eqo Home Cell Signal Booster for Single Room 474120

Discontinued by the manufacturer

Boost both voice & 4G data
Works with all major cellular carriers

Product Description

This product has been discontinued by the manufacturer. For a replacement, please see our other single-room cell phone signal booster systems.

Features of the weBoost eqo 4G

weBoost’s most powerful 4G consumer-grade cell phone signal booster for one room or office.
Quick and easy to set up and start receiving improved cell coverage.
Boosts 4G LTE and 3G service for voice, text, and data.
Works with all major U.S. cellular carriers and networks.
Boosts cell signal for multiple users in the same room.

The weBoost eqo cell phone signal booster (pronounced "echo") provides maximum power for the best possible cellular reception in a single room or office. Stay connected with the strongest cell signal, and experience fewer dropped calls, undelivered texts, and missed email messages. Keep your data moving faster in areas with weak cell service and in buildings that block outside cell signal.

Who is the weBoost eqo 4G for?

Those who frequently experience dropped calls, undelivered texts, or slow 4G internet at home.
Those who spend most of their time in the same workroom or office and need improved cellular reception in their workspace.
Apartment renters, college students, and others who are unable to place an antenna on the roof and pull cables through the walls.
Homes in remote locations with weak cell service (new communities, rural areas, cabins, etc.)
Homes with building materials that block outside cell signal (plaster, concrete, UV-coated windows, etc.).

Do-it-yourself installation

You can install the weBoost eqo yourself in minutes, without climbing on your roof or pulling cables through walls. (See Documentation, below, to download the installation guide.)

The newly-redesigned eqo 4G now includes an optional outside antenna that you may place between an outside window and the window screen. An attached flat coax cable runs under the windowsill. If you prefer not to use the outside antenna, the booster unit itself can also communicate with the cell tower.

The eqo 4G includes an outside antenna designed to be placed between a window and a window screen (click to enlarge).

weBoost eqo 4G kit contents

This is a complete kit, with everything you need to start getting the best signal in your home:

weBoost eqo 4G cell signal amplifier

weBoost eqo 4G inside antenna

weBoost eqo 4G outside antenna with 3′ flat coax cable

AC wall outlet power supply 850003

6′ (flat) and 25′ RG58 coax cables

weBoost eqo 4G user manual

How it works

Using Wilson Electronics’ patented SmarTech III® technology, the eqo 4G receives the outside cell signal, amplifies it, and rebroadcasts it inside your room. This allows you to stay connected in areas where cell service is poor, or where your home or office’s building materials interfere with signals from the local cell tower.

Works with all major cellular carriers

The weBoost eqo 4G works with all major wireless carriers, including Verizon, AT&T, T‑Mobile, Sprint, U.S. Cellular, and most others.

It operates on common 4G/3G cellular frequencies.

700 MHz (SMH) bands 12, 13, 17.
850 MHz (Cellular 850) band 5.
1700/2100 MHz (AWS) band 4.
1900 MHz (PCS) bands 2, 25.

How much area will this product cover?

The eqo 4G is designed to amplify cellular transmissions inside a single small room or office.

This system comes with one panel antenna that will broadcast improved cellular signal in a 180° arc. The broadcast distance depends on many factors, including:

Outside cell signal strength received by the donor antenna.
Inside building materials. (Cellular frequencies pass through wood framing and drywall more easily than through steel and concrete.)
Cellular frequencies used by the carrier. (Lower-frequency LTE and 800 MHz signals travel farther than higher-frequency AWS and PCS signals.)

In general, the stronger the outside cell signal, the greater the interior broadcast distance.

Powerful Signal has over a decade of experience designing and installing cellular amplification systems. Please call us at 866‐912‐3444 or contact us online, and we’ll be happy to calculate the coverage area this system will provide in your building and answer any other questions about this amplifier.
