weBoost Connect 4G Cell Phone Signal Booster for Homes 470103: Kit

weBoost Connect 4G Home Cell Signal Booster for Homes 470103

Discontinued by the manufacturer
Bulk Pricing:
Buy in bulk and save
  • Most economical solution for small homes
  • Boost both voice & 4G data
  • Works with all major cellular carriers
Outside Signal Strength
Coverage @ 700 MHz LTE
5 Bars
Up to 5,000 ft²
3 Bars
Up to 3,500 ft²
1 Bar
Up to 1,000 ft²

Discontinued

Free lifetime support
SKU: 470103

Product Description

This product has been discontinued and replaced by the weBoost Home MultiRoom 470144.

Features of the weBoost Connect 4G

  • Boosts cell signal in your home for multiple users.
  • Boosts 4G LTE and 3G service for voice, text, and data.
  • Works with all major U.S. cellular carriers and networks.

The weBoost Connect 4G cell phone signal booster has been designed to provide maximum power for the best possible cellular reception in your home. Stay connected with the strongest cell signal, and experience fewer dropped calls, undelivered texts, and missed email messages. Keep your data moving faster in areas with weak cell service and in buildings that block outside cell signal.

Who is the weBoost Connect 4G for?

  • Those who frequently experience dropped calls, undelivered texts, or slow 4G internet at home.
  • Homes in remote locations with weak cell service (new communities, rural areas, cabins, etc.)
  • Homes with building materials that block outside cell signal (plaster, concrete, UV-coated windows, etc.).

Do-it-yourself installation

You can install the weBoost Connect 4G yourself in a few hours. (See Documentation, below, to download the installation guide.)

Alternatively, you can have a professional install your booster system at additional cost. We recommend that you contact a local cable/satellite TV installer; the work required to install a cell signal booster is similar to installing a satellite dish TV service.

weBoost Connect 4G kit contents

This is a complete kit, with everything you need to start getting the best signal in your home:

weBoost Connect 4G 470103 icon weBoost Connect 4G cell signal amplifier
Wilson Electronics power supply 850011 icon AC wall outlet power supply 850011
Wilson Electronics LPDA antenna 314475 icon Wideband outdoor directional antenna 314475
Wilson Electronics panel antenna 311155 icon Wideband indoor panel antenna 311155
Wilson Electronics RG6 coax cable 30 feet 950630 & 15 feet 950615 icon 30′ (×1) & 15′ (×2) RG6 coax cable 950630/950615
Wilson 951177 RG58U coax 10 in. F-female Connectors icon 10″ RG58U flat coax with F‑female connectors
U-bolt bracket icon U-bolt pole-mount bracket (×2)
Wilson Electronics panel antenna wall mount 901143 icon Wall mount for panel antenna 901143
weBoost Connect 4G 470103 user manual icon weBoost Connect 4G user manual & quick install guide

How it works

Using Wilson Electronics’ patented SmarTech III® technology, the Connect 4G receives the outside cell signal, amplifies it, and rebroadcasts it inside your home. This allows you to stay connected in areas where cell service is poor, or where your home’s building materials interfere with signals from the local cell tower.

Works with all major cellular carriers

The weBoost Connect 4G works with all major wireless carriers, including Verizon, AT&T, T‑Mobile, Sprint, U.S. Cellular, and most others.

It operates on common 4G/3G cellular frequencies.

  • 700 MHz (SMH) bands 12, 13, 17.
  • 850 MHz (Cellular 850) band 5.
  • 1700/2100 MHz (AWS) band 4.
  • 1900 MHz (PCS) bands 2, 25.
Carrier logos for Verizon, AT&T, Sprint, T‑Mobile, U.S. Cellular

How much area will the weBoost Connect 4G cover?

The Connect 4G is designed to amplify cellular transmissions inside a small home or two to three rooms in a larger home.

This system comes with one panel antenna that will broadcast improved cellular signal in a horizontal cone shape. The distance from the antenna with usable cell signal depends on many factors, including:

  • Outside cell signal strength received by the donor antenna.
  • Inside building materials. (Cellular frequencies pass through wood framing and drywall more easily than through steel and concrete.)
  • Cellular frequencies used by the carrier. (Lower-frequency LTE and 800 MHz signals travel farther than higher-frequency AWS and PCS signals.)

In general, the stronger the outside cell signal, the greater the interior broadcast distance.

Powerful Signal has over a decade of experience designing and installing cellular amplification systems. Please call us at 866‐912‐3444 or contact us online, and we’ll be happy to calculate the coverage area this system will provide in your building and answer any other questions about this amplifier.

FCC notice

For information on federal rules governing the use of consumer cell signal boosters, please see our FCC notice page.

Prop 65 notice

Caution triangle icon Warning This product can expose you to chemicals, including nickel, which is known to the State of California to cause cancer, and Bisphenol A, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Product Specifications

Usage:
Small home
Strong outside signal (−95 dBm RSRP, 5 bars):
Up to 5,000 ft² indoor coverage @ 700 MHz
Fair outside signal (−105 dBm RSRP, 3 bars):
Up to 3,500 ft² indoor coverage @ 700 MHz
Weak outside signal (−115 dBm RSRP, 1 bar):
Up to 1,000 ft² indoor coverage @ 700 MHz
Outside Antenna:
Directional LPDA (×1)
Inside Antenna:
Directional panel (×1)
Cable Type:
RG6
Connector Type:
F
Impedance:
75 Ω
Gain/Loss:
+65 dB max
Booster Case Material:
Plastic
Signal Readout:
LED light

Warranty Information

For warranty information on this product, please see our weBoost warranty information page.
