weBoost Connect 4G‑X Cell Phone Signal Booster for Homes with Bonus Dome Antenna 471104: Kit

weBoost Connect 4G-X Home Cell Signal Booster Bonus Dome Antenna 471104

In stock—fast shipping!
  • Bonus dome antenna: use panel or dome
  • Bonus roof antenna mount & lightning surge protector
  • Boost both voice & 4G data
  • All major cellular carriers including Verizon, AT&T, T-Mobile, Sprint

SKU: 471104-A
Calculated at Checkout
Powerful Signal has been in business over 10 years Powerful Signal is Wilson Electronics' most experienced partner Powerful Signal offers lifetime support on all systems it sells Powerful Signal offers nationwide installation

Product Description

Features of the weBoost Connect 4G‑X

  • weBoost’s most powerful 4G consumer-grade cell phone signal booster for homes.
  • Boosts 4G LTE and 3G service for voice, text, and data.
  • Works with all major U.S. and Canadian carriers.
  • Boosts cell signal in your home for multiple users.
  • Includes two inside broadcast antennas: a wall-mount panel antenna and a bonus ceiling-mount dome antenna.

The weBoost Connect 4G‑X cell phone signal booster provides maximum power for the best possible cellular reception in your home. Stay connected with the strongest cell signal, and experience fewer dropped calls, undelivered texts, and missed email messages. Keep your data moving faster in areas with weak cell service and in buildings that block outside cell signal.

Who is the weBoost Connect 4G‑X for?

  • Those who frequently experience dropped calls, undelivered text, or slow 4G internet at home.
  • Homes in remote locations with weak cell service (new communities, rural areas, cabins, etc.)
  • Homes with building materials that block outside cell signal (plaster, concrete, UV-coated windows, etc.).
  • Homes with basements, theater rooms, metal out-buildings, and other places where cell reception is poor.

Do-it-yourself installation

You can install the weBoost Connect 4G‑X yourself in a few hours. (See Documentation, below, to download the installation guide.)

Alternatively, you can have a professional install your booster system at additional cost. Please contact us and we’ll put you in touch with an installer in your area.

Which antenna should I use?

This kit includes two inside antennas: a panel antenna that mounts on a wall, and a dome antenna that mounts on a ceiling. You may use either antenna, but not both together.

  • The panel antenna is directional, focusing its broadcast signal outward in a cone shape, similar to the light from a flashlight. It is easier to install than a dome antenna, but provides a more limited area of coverage.
  • The dome antenna is omnidirectional, broadcasting downward in 360° spread. Setup requires a ladder and access above the ceiling, so it is more complex to install; however, it provides a greater area of amplified signal.

You may use whichever antenna best suits your needs.

Panel antenna and dome antenna Panel antenna (left) and dome antenna (right)

weBoost Connect 4G‑X kit contents

This is a complete kit, with everything you need to start getting the best signal in your home:

weBoost Connect 4G-X 471104 icon weBoost Connect 4G‑X cell signal amplifier
Wilson Electronics power supply 859900 icon AC wall outlet power supply 859900
Wilson Electronics LPDA antenna 314411 icon Wideband outdoor directional antenna 314411
Wilson Electronics panel antenna 311135 icon Wideband indoor panel antenna 311135
Top Signal dome antenna TS250374 icon BONUS
Wideband indoor dome antenna TS250374
Wilson Electronics 400 coax cable 75 feet 952375 icon 75' 400 coax cable 952375
Wilson Electronics 400 coax cable 60 feet 952360 icon 60' 400 coax cable 952360
Top Signal adjustable rooftop antenna mount TS430001 icon BONUS
Adjustable rooftop antenna mount TS430001
Top Signal 50-ohm lightning surge protector TS450001 icon BONUS
50‑ohm lightning surge protector TS450001
weBoost Connect 4G-X 471104 user manual icon weBoost Connect 4G‑X user manual & quick install guide

How the weBoost Connect 4G‑X works

Using Wilson Electronics’ patented SmarTech III® technology, the weBoost Connect 4G‑X system receives the outside cell signal, amplifies it, and rebroadcasts it inside your office through four inside antennas. This allows you to stay connected in areas where cell service is poor, or where your office’s building materials interfere with signals from the local cell tower.

Works with all major cellular carriers

The weBoost Connect 4G‑X works with all major wireless carriers:

  • U.S. carriers, including Verizon, AT&T, T‑Mobile, Sprint, U.S. Cellular, and most others.
  • Canadian carriers, including Rogers, Bell Canada, Telus, Wind, and most others.

It operates on common 4G/3G cellular frequencies.

  • 700 MHz (SMH) bands 12, 13, 17.
  • 850 MHz (Cellular 850) band 5.
  • 1700/2100 MHz (AWS) band 4.
  • 1900 MHz (PCS) bands 2, 25.
Carrier logos for Verizon, AT&T, Sprint, T‑Mobile, U.S. Cellular

How much area will the weBoost Connect 4G‑X cover?

This system comes with one panel antenna that will broadcast improved cellular signal in a conical pattern, and one dome antenna that will broadcast in a circular pattern. The broadcast distance/radius depends on many factors, including:

  • Outside cell signal strength received by the donor antenna.
  • Inside building materials. (Cellular frequencies pass through wood framing and drywall more easily than through steel and concrete.)
  • Cellular frequencies used by the carrier. (Lower-freqency LTE and 800 MHz signals travel farther than higher-frequency AWS and PCS signals.)

In general, the stronger the outside cell signal, the greater the interior broadcast distance.

Powerful Signal has over a decade of experience designing and installing cellular amplification systems. Please call us at 866‐912‐3444 or contact us online, and we’ll be happy to calculate the coverage area this system will provide in your building and answer any other questions about this amplifier.

FCC Notice

This is a CONSUMER device. BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider and have your provider’s consent. Most wireless providers consent to the use of signal boosters. Some providers may not consent to the use of this device on their network. If you are unsure, contact your provider. You MUST operate this device with approved antennas and cables as specified by the manufacturer. Antennas MUST be installed at least 20 cm (8 inches) from any person. You MUST cease operating this device immediately if requested by the FCC or a licensed wireless service provider. WARNING. E911 location information may not be provided or may be inaccurate for calls served by using this device.

Please note: The four largest carriers (Verizon, AT&T, T‑Mobile, and Sprint) and more than 90 regional carriers have given blanket consent for use of all boosters that are certified to the 2013 FCC standards. Go to our Cell Phone Signal Booster Registration page and follow the links for your carrier. There are no fees to register your cell signal booster.

If you have any questions, please contact Powerful Signal.

Product Specifications

Large home or small office
Outside antenna:
Directional LPDA (×1)
Inside Antenna:
Directional panel (×1) & omnidirectional dome (×1)
Cable Type:
Connector Type:
50 Ω
+70 dB max
Booster Case Material:
Signal Readout:
LED light

Warranty Information

weBoost signal boosters and kits are warranted for two (2) years against defects in workmanship and/or materials. Warranty cases may be resolved by returning the product directly to the reseller with a dated proof of purchase. See reseller warranty procedures.

Signal boosters and kits may also be returned directly to the manufacturer at the consumer’s expense, with a dated proof of purchase and a returned material authorization (RMA) number supplied by weBoost. weBoost shall, at its option, either repair or replace the product. weBoost will pay for delivery of the repaired or replaced product back to the original consumer if located within the continental U.S.

This warranty does not apply to any signal boosters or kits determined by weBoost to have been subjected to misuse, abuse, neglect, or mishandling that alters or damages physical or electronic properties.

Failure to use a surge-protected AC power strip with at least a 1000 Joule rating will void your warranty.

All weBoost products that are packaged with other weBoost accessory products are intended for resale and use as a single unit, and such product kits are required to be sold to the end user or subsequent reseller as packaged. The “de-kitting” and sale as a standalone product of any one or more components of such a product kit is in violation of weBoost’s warranty. No “de-kitted” product will be eligible for return for any reason.

The sale of separate, not-kitted cable, antennas, and other accessories is allowed and fully warranted.
