Top Signal TS420001 RF Explorer Signal Meter

Availability:
In stock—fast shipping!
    Flag Most powerful
    Feature Detect strength, distance, direction of existing cell signals
    Feature Detects 15–2700 MHz frequency range
    Usage Commercial
    Impedance 50 Ω
    Connector Type SMA-female (×2)
    Frequency Range 15 MHz–2700 MHz
    Frequency Span 112 kHz–600 MHz
    Amplitude Resolution 0.5 dBm
    Dynamic Range (Left SMA Port) −115 dBm–0 dBm
    Dynamic Range (Right SMA Port) −110 dBm–−10 dBm
    Max Input Power (Left SMA Port) +5 dBm
    Max Input Power (Right SMA Port) +30 dBm
    Average Noise Level (Typical) −110 dBm
    Frequency Stability & Accuracy (Typical) ±10 ppm
    Amplitude Stability & Accuracy (Typical) ±6 dBm
    Frequency Resolution 1 kHz
    Resolution Bandwidth (RBW) 3 kHz–600 kHz (automatic)
    Outside Signal Strength Coverage Area
    Qty:
      Brand:
      $289.95
      SKU: TS420001
      Shipping:
      Calculated at checkout
      Powerful Signal has been in business over 10 years Powerful Signal is Wilson Electronics' most experienced partner
      Powerful Signal offers lifetime support on all systems it sells Powerful Signal offers nationwide installation

      Top Signal TS420001 RF Explorer Signal Meter

      Product features

      • Detects cellular signal strength and direction.
      • Works indoors and outdoors.
      • Detects frequencies from 15 MHz to 2700 MHz (2.7 GHz), including cellular and WiFi. (See More Information for additional bands.)
      • Two SMA-female connectors attach to telescoping and whip external antennas (included) or to any antenna or cable with SMA-male connectors.
      • Solid aluminum case.
      • 128×64 backlit LCD screen with excellent indoor and outdoor visibility.
      • Mini-USB 2.0 connector (female) recharges built-in battery, connects to a PC for extra functionality. (Micro-USB cable not included.)

      Product use

      • Designed for professional installers to detect signal strength and distance when installing and troubleshooting WilsonPro and weBoost cell phone signal booster systems.

      Product includes

      • 1 × RF Explorer signal meter.
      • 1 × Nagoya NA-773 wideband telescoping antenna (for < 1000 MHz frequencies).
      • 1 × whip helical antenna (for > 1000 MHz frequencies).
      • 1 × hard-sided case (black).

      Product notes

      • Defective units may be returned for warranty exchange only. Working units may not be returned for cash or credit.

      Popular frequencies detected by the RF Explorer signal meter

      This list includes common, well-known frequencies that can be surveyed with the RF Explorer signal meter. For a complete list of allocated frequencies between 15 MHz and 2700 MHz, please consult this index.

      Frequency range
      Allocated to
      26.96–27.41 MHz
      Citizens band (CB) radio
      40 MHz
      Garage door openers, alarm systems
      40–50, 900 MHz
      Cordless home phones
      49 MHz
      Baby monitors
      50–54, 144–148, 216–220, 222–225 420–450, 902–928,
      1240–1300, 2300–2310, 2390–2450 MHz
      Amateur (ham) radio
      54–88, 174–216 MHz
      VHF television (channels 2–6, 7–13)
      88–108 MHz
      FM radio
      108–117.975, 1559–1610 MHz
      Global Positioning System (GPS)
      462.5625–467.7125
      Family band radio
      470–698 MHz
      UHF television (channels 14–51)
      699–787 MHz
      Cellular (SMH blocks)
      814–894 MHz
      Cellular (CLR blocks)
      1710–1755, 2110–2155 MHz
      Cellular (AWS blocks)
      1850–1995 MHz
      Cellular (PCS blocks)
      2305–2315, 2350–2360 MHz
      Cellular (WCS blocks, "WiMax")
      2400–2484 MHz
      WiFi (802.11b/g/n), Bluetooth, older cordless home phones
      2496–2690 MHz
      Cellular (BRS/EBS)
      Flag Most powerful
      Feature Detect strength, distance, direction of existing cell signals
      Feature Detects 15–2700 MHz frequency range
      Usage Commercial
      Impedance 50 Ω
      Connector Type SMA-female (×2)
      Frequency Range 15 MHz–2700 MHz
      Frequency Span 112 kHz–600 MHz
      Amplitude Resolution 0.5 dBm
      Dynamic Range (Left SMA Port) −115 dBm–0 dBm
      Dynamic Range (Right SMA Port) −110 dBm–−10 dBm
      Max Input Power (Left SMA Port) +5 dBm
      Max Input Power (Right SMA Port) +30 dBm
      Average Noise Level (Typical) −110 dBm
      Frequency Stability & Accuracy (Typical) ±10 ppm
      Amplitude Stability & Accuracy (Typical) ±6 dBm
      Frequency Resolution 1 kHz
      Resolution Bandwidth (RBW) 3 kHz–600 kHz (automatic)
      Introducing RF Explorer - Handheld Spectrum Analyzer (04:59)
      This is a brief video with a few screens of RF Explorer in action. It is not exhaustive nor demoes all the features, but you can get a good idea of performance and how easy is to use it. For more info visit us at http://www.rf-explorer.com. This video does not include any sound track, and it is freely available through Creative Commons license.
      • Introducing RF Explorer - Handheld Spectrum Analyzer
        This is a brief video with a few screens of RF Explorer in act...

      This product hasn't received any reviews yet. Be the first to review this product!

      Write your own product review

      Top Signal accessories are warranted for ninety (90) days against defects in workmanship and/or materials. Warranty cases may be resolved by calling Powerful Signal at 866-912-3444.

      This warranty does not apply to any accessories or components determined by Powerful Signal to have been subjected to misuse, abuse, neglect, or mishandling that alters or damages physical or electronic properties.
