Product Description
The Marine CEL-FI GO G32 cell phone signal booster improves cellular reception for boats and vessels that are moored and are underway. Stay connected on lakes, rivers, and coastal waters. Experience faster 5G/4G data and fewer dropped calls, undelivered texts, and missed email messages.
* 100 dB stationary mode is available only when the CEL-FI GO G32 booster is powered by the 120V AC power supply.
Poynting OMNI‑493 (left) & RFI CDQ7199 (right) to scale. (Click to enlarge.)
When having a usable cell phone signal in your boat isn’t a luxury, it’s a critical necessity.
The Poynting antenna connects to a 1″ × 14 thread marine mount (left) or to a 1½″‑2″ pole (right). (Click to enlarge.)
The Poynting OMNI-493 is the right choice if you need a shorter antenna or if you want the best reception for high-frequency cellular bands that have faster data rates. It has 6 dBi of gain on low-band cellular frequencies (617–960 MHz) and 9 dBi of gain on higher-band frequencies (1710–2700 MHz). Higher frequencies have a shorter range but offer faster data rates, so the Poynting OMNI-493 is the better option if faster data is more important for you than receiving signal at longer distances from cell towers.
The Poynting antenna attaches to a standard 1″ × 14 thread marine mount (with a ¾″ hole beneath the mount to run the coax cable) or to poles or posts 1½″ to 2″ in diameter. It’s also shorter than the RFI antenna, which may make it the better choice if you have minimum-clearance concerns for your vessel.
The Poynting OMNI-493 comes with your choice of 10′, 20′, 30′, 50′ or 75′ of low-loss TS-400 coax cable.
The RFI whip antenna is 81.9″ (208 cm) tall, or about 6′ 10″. (Click to enlarge.)
The RFI CDQ7199 is the right choice if you want the best reception for low-frequency cellular bands that have a longer range. It has 8.5 dBi of gain on low-band cellular frequencies (617–960 MHz) and 4.5 to 5.5 dBi of gain on higher-band frequencies (1710–2700 MHz). Lower frequencies offer slower data rates but have a longer range, so the RFI CDQ7199 is the better option if receiving signal at longer distances from cell towers is more important for you than having faster data speeds.
The RFI antenna attaches to a standard 1″ × 14 thread marine mount. It includes RFI’s Q‑Fit® threaded quick-release connector for fast, easy takedown and setup for low minimum-clearance passages—the antenna attaches and detaches from its base in seconds.
The RFI CDQ7199 includes 16.4′ (5 m) of attached RG58 coax cable. You may extend that with a 10′, 20′, 30′, or 50′ run of low-loss TS-400 coax cable.
The Nextivity WAVE app for smartphones lets you check your CEL-FI GO G32 booster’s status and change its settings:
You can install the Marine CEL-FI GO G32 yourself. It does not require professional help, although you can hire a marine electronics specialist to do the job for you.
Click here to download the two-page PDF installation guide for instructions and tips on setting up this system in your boat.
(Learn more about marine antenna mounting options and antenna separation.)
This is a complete kit, with everything you need to start getting the best signal in your vessel:
CEL-FI GO G32 Smart Signal Booster
AC power supply 290N039‑001
12V DC vehicle power supply 290N035‑004
Top Signal EDGE indoor panel antenna TS260820 (w/mounting hardware)
Choice of:
Top Signal SMA‑female to N‑male connector TS451033
CEL-FI GO G32 quick start guide
Marine CEL-FI GO G32 high‑gain installation guide TS053039
Optional add‑onThe Poynting OMNI-493 antenna kit includes:
Antenna
Adapter base w/ring seal & side‑exit port
Locking nut
Allen cap screws, nuts & washers (×4 ea.)
Allen key
L‑bracket & U‑bolts
Poynting OMNI‑493 user guide
Choice of:
2′ Top Signal RG58U coax with N‑female & SMA‑male connectors TS386002
Top Signal 2′ TS‑195 coax w/N‑male & SMA‑male connectors
Top Signal SMA‑female to N‑female connector TS451041
The RFI CDQ7199 antenna kit includes:
RFI 81.9″ white fiberglass whip antenna
Ferrule with 16.4′ white RG58 coax cable
Top Signal FME‑male to SMA‑male connector TS451019
Optional add‑on
Optional add‑on
Optional add‑onThe Nextivity CEL-FI GO G32 Smart Signal Booster system works with Verizon, AT&T, T‑Mobile, UScellular, and GCI Alaska 5G and 4G/LTE cellular bands. It does not work with other cellular networks.
The CEL-FI GO G32 operates on two cellular bands simultaneously from a single carrier. It will support only one carrier at a time.
Not sure which bands your phone uses? Contact us—our technical support reps will be happy to help you!
The Top Signal EDGE panel antenna has four installation configurations:
The back of the panel includes a channel for the pigtail cable so it will mount flush against walls and ceilings.
Command™ brand is a trademark of 3M.
The removable nylon post and nut give you the option of mounting the EDGE panel antenna vertically on a drillable ceiling. (Click to enlarge.)
For information on federal rules governing the use of consumer cell signal boosters, please see our FCC notice page.
Warning This product can expose you to chemicals, including nickel, which is known to the State of California to cause cancer, and Bisphenol A, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
.
Product Specifications
Warranty Information
For warranty information on this product, please see our Nextivity warranty information page.
