Features of the Top Signal 50‑ohm lightning surge protector
N‑male connector on one end; N‑female connector on the other end.
No jumper cable required: N‑male end connects to antenna; N‑female end connects to coax cable running to booster.
0–3000 MHz frequency range.
50 ohm impedance.
Attenuates < −0.2 dB.
How the Top Signal 50‑ohm lightning surge protector is used
When properly installed and attached to a ground wire, this gas-discharge surge protector interrupts the spike in power from a nearby lightning strike, directing it to ground instead of to a cell signal booster.
Gas discharge element is replaceable.
For in-building use with 50-ohm cell signal booster systems and ½‑inch, 400, or 240 coax cable terminated with N‑male connectors.
Top Signal 50‑ohm lightning surge protector contents
50‑ohm lightning surge protector TS450001
Please note
Requires an additional ground cable (not included).
This product will not protect against a direct lighting strike to an antenna. If you are concerned about lightning strikes, we recommend installing a lightning rod suitable to your building.
50‑ohm lightning surge protector TS450001
