    Wilson Outdoor Directional LPDA/Yagi Cellular Antenna 698–2700 MHz F-Female 314475

    Call for bulk pricing on orders of 10 or more! 866-912-3444
    Bulk Pricing:
    Buy in bulk and save

    Tier Price Rates

    • Outdoor building antenna for 75 Ohm systems
    • “Pigtail” cable with F-female connector
    • Attaches to pole mount (optional add-on)
    • U-bolt bracket (included)

    Free lifetime support
    $89.99
    SKU: 314475
    Shipping:
    Calculated at Checkout

    Product Description

    Features of the Wilson outdoor LPDA antenna

    • Works with 698–2700 MHz 5G and 4G/LTE frequencies. (Learn more about 5G compatibility.)
    • 11.4″ directional building antenna.
    • Mounts on pole 1.5–2.0 inches in diameter (mounting bracket included; pole sold separately).
    • F‑female connector with “pigtail” cable attachment.
    • 75‑ohm impedance.
    • +7.3–10.6 dBi gain.
    • Beamwidth: Horizontal plane 100°–109°/70°–85°, vertical plane 65°/55°.
    • Assembled in USA.
    • 2‑year warranty.

    How the Wilson outdoor LPDA antenna works

    • Receives outside signal from a cell phone tower and directs it to a cell phone signal booster.
    • For use outside commercial buildings, offices, and homes.
    • Works with 75‑ohm cell signal booster systems.

    Learn more about LPDA antennas in our Knowledge Base article, “What’s the difference between an LPDA antenna and a Yagi antenna?”

    Wilson outdoor LPDA antenna contents

    Wilson Outdoor Pole-Mount Directional LPDA Antenna with F-Female Connector (75 Ohm) 314475 icon Wideband outdoor LPDA antenna 314475
    Outdoor antenna U-bolt and bracket set icon Threaded U-bolt and bracket (×2)
    Top Signal Adjustable Building Antenna Mount TS430001 icon Optional add-on
    18″ adjustable building mount TS430001
    Top Signal TS450002 Lightning Surge Protector 75 Ohm F-Male/F-Female icon Optional add-on
    75-ohm lightning surge protector TS450002

    Please note

    • This antenna will not operate by itself; it is one component of a cell signal booster system. Please contact Powerful Signal—we’ll be happy to help you determine what your needs are and what system will work best in your situation.

    Product Specifications

    Usage:
    Office/residential
    Connector Type:
    F-female
    Cable Type:
    RG-6 or RG-11 coax
    Cable Length:
    (none)
    Antenna Type:
    Outside directional
    Antenna Length:
    11.4 in. (29 cm)
    Polarization:
    Vertical
    Mount Type:
    U-bolt bracket
    Mount Spec:
    Attaches to 1.5–2.0 in. poles
    Impedance:
    75 Ω
    Gain 698–814 MHz:
    +7.48 dBi
    Gain 814–960 MHz:
    +7.31 dBi
    Gain 1695–2180 MHz:
    +8.83 dBi
    Gain 2180–2700 MHz:
    +8.57 dBi
    Beamwidth Horizontal Plane:
    100°–109° (low band) / 70°–85° (high band)
    Beamwidth Vertical Plane:
    65° (low band) / 55° (high band)
    Prop 65 Notice:
    Warning Cancer and reproductive harm. www.P65Warnings.ca.gov

    Warranty Information

    For warranty information on this product, please see our Wilson Electronics warranty information page.
