Product Description
Features of the Top Signal 4‑way 50‑ohm splitter
- One N‑female input, four N‑female outputs.
- 700–2700 MHz frequency range.
- 50 ohm impedance.
- Attenuates < −6.6 dB.
The Top Signal 4-way splitter attenuates −6.6 dB to each antenna. (Click to enlarge.)
How the Top Signal 4‑way 50‑ohm splitter is used
- Splits a single run of coax cable equally into four separate runs to indoor antennas.
- For in-building use with 50-ohm cell signal booster systems and ½‑inch, 400, or 240 coax cable terminated with N-male connectors.
Top Signal 4‑way 50‑ohm splitter contents
4‑way N‑female 50‑ohm splitter TS414001
Please note
- Because of the signal loss (attenuation) involved, we recommend using a splitter only if you have strong outside signal.
- Users with weak outside signal should consider purchasing multiple, independent cell phone signal booster systems instead of splitting the signal from a single booster.
Product Specifications
Splits Signal:
4 ways
Input Ports:
1
Output Ports:
4
Connector Type:
N-female
Cable Type:
240, 400 & ½-inch coax
Frequency Range:
700–2700 MHz
Impedance:
50 Ω
Gain/Loss:
≤ −6.6 dB per output port
Warranty Information
For warranty information on this product, please see our Top Signal warranty information page.
Top Signal TS414001 spec sheet (PDF)
The Top Signal 4-way splitter attenuates −6.6 dB to each antenna. (Click to enlarge.)
