Poynting PUCK-12 2×2 MIMO WiFi Antenna 7.5 dBi 2400/5000 MHz SMA-Male | A-PUCK-0012-V1-01-W | TS210612W

Poynting PUCK-12 2×2 MIMO WiFi Antenna 7.5 dBi 2400/5000 MHz SMA-Male TS210612W

WiFi antenna with 6 mounting options & excellent gain
Bulk Pricing:
Buy in bulk and save
  • Low-profile WiFi omni antenna with up to 7.5 dBi of gain
  • Durable housing for interior or exterior use in homes, offices, RVs, trailers, vans, boats & ships
  • Attached 2 × 6.6′ RTK031 coax cables with SMA-male connectors
  • Includes magnetic base, 3M® adhesive pad, 2 spigot mounts & pole/wall-mount bracket
  • Works with WiFi routers & hotspots with 2 × WiFi antenna ports

Free lifetime support
$79.99
SKU: TS210612W
Shipping:
Calculated at Checkout

Product Description

Connects to a cellular–WiFi router, hotspot, or modem. Does not connect to a cell signal booster.

Features of the Poynting PUCK-12 2×2 MIMO WiFi antenna

  • 3.9″ ᴅ × 1.4″ ʜ (99.3 × 36 mm) omnidirectional WiFi antenna.
  • Broadcasts dual-band 2.4 & 5 GHz WiFi signal concurrently, with 2×2 MIMO support for 802.11n and 802.11ac/ax wireless networking standardsexternal link icon.
  • 5.0 dBi gain on 2.4 GHz; 7.5 dBi gain on 5.0–7.2 GHz.
  • Two 6.6′ (2 m) SMA‑male RTK031 coax cables connect to WiFi (×2) ports on a cellular–WiFi router, modem, or hotspot. The cables are enclosed in a braided protection sleeve. Two RP-SMA/SMA adapters included.
  • Works in homes, commercial buildings, RVs, trailers, vans, boats, ships, and other applications.
  • Six mounting options (mounting accessories included, except where noted):
    1. Magnetic base attaches to a steel or iron surface. (Includes a side-exit channel for the coax cable.)
    2. Surface mount attaches securely to non-magnetic surfaces with a double-sided 3M® foam adhesive pad.*
    3. Spigot mount attaches through a 0.8″ (20 mm) hole with 1.2″ (30 mm) or 2.75″ (70 mm) two-piece threaded spigot posts and nut.
    4. Pipe mount bracket attaches to a vertical or horizontal pole. (Requires a cable tie or hose clamp, purchased separately.)
    5. Wall mount bracket attaches to a drillable vertical surface with screws of appropriate length (purchased separately).
    6. Panel mount attaches through a thin surface with M4×10 mm bolts (included) or through a thicker drillable surface with longer M4 bolts (purchased separately).*
  • The rugged PC+ABS radome is IK10 impact-ratedexternal link icon and IP 69K-ratedexternal link icon for protection against water immersion and dust. It’s also rated for wind conditionsexternal link icon up to 135 ᴍᴘʜ (220 ᴋᴘʜ ), depending on the selected mounting option.
  • Ground plane-independent.
  • 50‑ohm impedance.
  • 2‑year warranty.

* Requires a drilled entry point below the center the antenna to run the coax cable bundle.

Peplink MAX BR1 Pro 5G antenna connectors The Poynting PUCK-12 2×2 MIMO WiFi antenna has 2 coax cables that connect to the 2 WiFi connectors on routers like this Peplink MAX BR1 Pro 5G.

Installation

The Poynting PUCK-12 WiFi antenna has six mounting options for flexible use as a broadcast antenna inside your vessel or as an outside donor antenna.

Click here to download the PDF user guide with installation instructions.

Poynting PUCK-12 Vehicle/IoT 2x2 MIMO WiFi Antenna A-PUCK-0012-V1-01-W TS210616W magnet mount Magnet mount

(cable side exit)
Poynting PUCK-12 Vehicle/IoT 2x2 MIMO WiFi Antenna A-PUCK-0012-V1-01-W TS210616W surface mount Surface mount
with 3M® adhesive pad

(cable side exit)
Poynting PUCK-12 Vehicle/IoT 2x2 MIMO WiFi Antenna A-PUCK-0012-V1-01-W TS210616W spigot mount Spigot mount
with 30 mm or 70 mm spigot

(cable bottom exit)
Poynting PUCK-12 Vehicle/IoT 2x2 MIMO WiFi Antenna A-PUCK-0012-V1-01-W TS210616W pipe mount Horizontal or vertical pipe mount

(cable side or bottom exit; zip tie or hose clamp required)
Poynting PUCK-12 Vehicle/IoT 2x2 MIMO WiFi Antenna A-PUCK-0012-V1-01-W TS210616W wall mount Wall mount

(cable side or bottom exit; additional screws required)
Poynting PUCK-12 Vehicle/IoT 2x2 MIMO WiFi Antenna A-PUCK-0012-V1-01-W TS210616W panel mount Panel mount

(cable side exit; longer M4 bolts may be required)

Poynting PUCK-12 antenna contents

Poynting PUCK-12 Vehicle/IoT 2x2 MIMO WiFi Antenna A-PUCK-0012-V1-01-W TS210616W icon Antenna w/2 m dual RTK031 coax cable & SMA-male connectors A-PUCK-0012-V1-01-W
Poynting PUCK-12 Vehicle/IoT 2x2 MIMO WiFi Antenna A-PUCK-0012-V1-01-W M4 Screws icon M4 screws (×4)
Poynting PUCK-12 Vehicle/IoT 2x2 MIMO WiFi Antenna A-PUCK-0012-V1-01-W Magnetic Base Plate icon Magnetic base plate
Poynting PUCK-12 Vehicle/IoT 2x2 MIMO WiFi Antenna A-PUCK-0012-V1-01-W 3M Foam Adhesive Pad icon 3M® foam adhesive pad
Poynting PUCK-12 Vehicle/IoT 2x2 MIMO WiFi Antenna A-PUCK-0012-V1-01-W 70 mm Spigot icon 70 mm spigot
Poynting PUCK-12 Vehicle/IoT 2x2 MIMO WiFi Antenna A-PUCK-0012-V1-01-W 30 mm Spigot icon 30 mm spigot
Poynting PUCK-12 Vehicle/IoT 2x2 MIMO WiFi Antenna A-PUCK-0012-V1-01-W Spigot Nut icon Spigot nut
Poynting PUCK-12 Vehicle/IoT 2x2 MIMO WiFi Antenna A-PUCK-0012-V1-01-W Pole/Wall Bracket icon Pole/wall bracket
Poynting PUCK-12 Vehicle/IoT 2x2 MIMO WiFi Antenna A-PUCK-0012-V1-01-W RP-SMA to SMA adapters icon RP-SMA to SMA adapters (×2)
Poynting PUCK-12 Vehicle/IoT 2x2 MIMO WiFi Antenna A-PUCK-0012-V1-01-W User Guide icon Poynting PUCK-12 user guide

Product Specifications

Usage:
Home/office/vehicle/marine
Antenna Type:
Indoor/outdoor omnidirectional WiFi
Antenna Length:
3.9 in. (9.93 cm) W × 1.4 in. (3.6 cm) H
Polarization:
Vertical
Connector Type:
SMA-male / RP-SMA-male
Cable Type:
RTK031
Cable Length:
6.6 ft. (2 m)
Mount Type:
Magnetic, adhesive, spigot, pole/wall bracket
Mount Spec:
Attaches to steel, poles, flat surfaces, drillable surfaces
Impedance:
50 Ω
Gain 2400–2500 MHz:
+5.0 dBi
Gain 5000–7200 MHz:
+7.5 dBi
VSWR:
<2.5:1
Beamwidth Horizontal Plane:
360°

Warranty Information

For warranty information on this product, please see our Poynting warranty information page.
