WilsonPro IoT 3.0 Direct-Connect SISO Cell Signal Amplifier

For IoT / M2M applications
Reliable signal for cellular modems in remote locations or inside buildings
Compact form factor
SMA, MCX & MMCX connectors
Power over coax & passive RF bypass failover

Product Description

Features of the WilsonPro IoT 3.0

Designed to link with a cellular data modem as a direct-connect amplifier.
Improves 5G and 4G/LTE cellular connectivity in weak signal environments. (Learn more about 5G compatibility.)
Configurable to almost any IoT (Internet of Things)/M2M (machine-to-machine) installation. The compact form factor easy to install next to or inside most machines.
Power-over-coax design allows the amplifier and antenna to be positioned for maximum performance.
Passive RF bypass failover allows the modem to continue operating if power is lost to the booster.
Auto-power control to help ensure maximum signal output.
Carrier agnostic: Works with all major U.S. cellular carriers and networks.
Designed and assembled in St. George, Utah.

The WilsonPro IoT 3.0 is designed to amplify wireless cellular communications to and from unattended machine devices, including retail point-of-sale, kiosks, ATMs, remote monitoring/control, data backup, Internet failover, and other applications.

Based on the same proven technologies as Wilson Electronics’s other cellular DAS and booster systems but in a small form factor, the IoT 3.0 provides reliable data transfer in remote areas; in interior, data center, or basement rooms of commercial and industrial buildings; for cellular routers; and in other situations where cellular reception is weak or spotty.

WilsonPro IoT 3.0 vending machine setup diagram

WilsonPro IoT 3.0 security setup diagram

Who is the WilsonPro IoT 3.0 for?

Remote monitoring and control devices deployed in areas with weak cell coverage (oil fields, farms, utilities, environmental tracking stations, etc.).
Vending machines and kiosks (ATMs, movie rental boxes, hot/cold beverages and snacks, ticketing machines, etc.).
Keypad security panels.
Retail point-of-sale (POS) devices in remote areas or inside buildings that block cell reception.
Cellular modems used in remote locations where cable, DSL, and fiber internet aren’t available.
Automated data backup from computing devices in remote locations or buildings with poor inside cellular reception.
Data-transmission devices with wired communications that use cellular as a backup or failover option.

Purchasing a WilsonPro IoT 3.0

This system includes the following components:

WilsonPro IoT 3.0 amplifier 460079

Amplifier wall mount bracket

Power over coax unit ACC000084

120V AC wall outlet power supply PWR000048

12V DC hardwire power supply with fuse CBL000113

External hinged paddle antenna ANT000058

20′ coax cable N-male/N-male CBL000140

1′ coax cable SMA-male/SMA-male CBL000141

1′ coax cables SMA-male/MCX-female 299153 & SMA-male/MMCX-female 291154

WilsonPro IoT 3.0 installation guide

Works with all major cellular carriers

The WilsonPro IoT 3.0 works with all major wireless carriers, including Verizon, AT&T, T-Mobile, DISH Wireless, UScellular, GCI Alaska, and most others.

It operates on common cellular frequencies.

700 MHz (SMH) bands 12, 13, 17.
850 MHz (Cellular 850) band 5.
1700/2100 MHz (AWS) band 4.
1900 MHz (PCS) bands 2, 25.

T-Mobile customers please read about band 71 and cell signal boosters

Documentation

WilsonPro IoT 3.0 spec sheet (PDF)

Download the WilsonPro IoT 3.0 460079 installation guide (PDF)

WilsonPro IoT 3.0 installation guide (PDF)

What’s my actual cell signal strength?

FCC notice

For information on federal rules governing the use of consumer cell signal boosters, please see our FCC notice page.

Prop 65 notice

Caution triangle icon Warning This product can expose you to chemicals, including nickel, which is known to the State of California to cause cancer, and Bisphenol A, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
