    HiBoost SLW Smart Link Commercial Cell Signal Booster

    Discontinued
    Bulk Pricing:
    Buy in bulk and save

    Tier Price Rates

    • Commercial/professional system
    • Covers up to 35,000 square feet
    • Supports hundreds of cell phone users simultaneously
    • Choice of directional or omnidirectional outdoor antenna
    • Choice of 1 to 4 high-performance EDGE indoor dome or panel antennas
    • Automatic or adjustable gain
    • Boosts voice, text & 5G/4G data for all major carriers
    • Includes Smart Link Bluetooth monitoring capability
    Outside Signal Strength
    Coverage @ 700 MHz LTE
    5 Bars
    Up to 35,000 ft²
    3 Bars
    Up to 20,000 ft²
    1 Bar
    Up to 3,000 ft²

    Discontinued

    Free lifetime support
    SKU: Pro25-5S-BTW

    Product Description

    This system has been discontinued and replaced by the HiBoost Pro25T-6s.

    Features of the HiBoost SLW Smart Link

    • Maximum coverage for large businesses, public buildings, and large custom homes.
    • Heavy-duty metal case with heat sink.
    • Easy-to-read backlit LCD display, with uplink/downlink/power status on one screen and optional manual settings.
    • Monitor and troubleshoot your booster with HiBoost’s Signal Supervisor app for smartphones.
    • Boosts signal for hundreds of simultaneous cellular devices.
    • Your choice of outside directional or omnidirectional antenna, plus your choice of one to four inside dual-mount dome antennas or flex-mount panel antennas. (Get help picking the right antennas.)
    • Includes commercial-grade antennas and components.
    • Carrier agnostic: Works with all major U.S. and Canadian carriers.
    • Improves 5G and 4G/LTE service for voice, text, and data. (Learn more about 5G compatibility.)

    The HiBoost SLW Smart Link is a single-antenna system designed for large offices, commercial buildings, and homes that need improved cell signal reception and have the highest user demands. The SLW Smart Link improves both voice and data to reduce dropped calls and missed emails and texts, keeping your business, employees, residents, and/or guests connected with a stronger cell signal.

    This system includes inside dome or panel antennas that send amplified signal to the phones in your building. You may customize your HiBoost SLW system by adding inside antennas, up to a total of four.

    HiBoost LCD display and controls The HiBoost SLW amplifier features a backlit LCD display and controls for gain and power.
    Upgrade option: Need more power or coverage? Get it here! Customers also like: Learn more about antenna and coverage options.

    Who is the HiBoost SLW Smart Link for?

    • Large offices and buildings with heavy cellular user and data loads.
    • Large, luxury, and custom homes.
    • Remote locations with weak cell service.
    • Urban locations with building materials that block outside cell signal (steel, glass, concrete, plaster, etc.).
    • Areas below ground level, and other places where cell reception is poor.
    • Large homes with basements, theater rooms, metal out-buildings, and other places where cell reception is poor.

    Monitor your SLW Smart Link system from your smartphone

    HiBoost’s Signal Supervisor app for smartphones helps you set up and monitor your cell signal booster. The booster links to your iPhone or Android smartphone via a Bluetooth or WiFi connection. With Signal Supervisor, you can:

    • Register your booster via a QR Code or Bluetooth.
    • Monitor your signal booster’s status via Bluetooth.
    • Set up and receive remote alerts if your booster isn’t operating properly.
    • View your booster’s power settings, gain, and dBm output.
    • Manage multiple boosters.

    HiBoost’s Signal Supervisor app is available for Apple iOSexternal link icon and Androidexternal link icon devices.

    The HiBoost Signal Supervisor app for iPhone and Android smartphones for use with HiBoost cell phone signal boosters
    Download on the App Store Get it on Google Play

    Best practices: a custom-designed HiBoost SLW Smart Link solution

    In a large building, office, warehouse, or custom home, you’ll get the best results and performance from a HiBoost SLW Smart Link with a custom design and professional installation.

    Working with your floor plans, Powerful Signal’s design engineers will create design specifications that will allow you to use the fewest number of components to get the maximum amount of cellular coverage inside your building.

    Powerful Signal’s professional installer will have knowledge of local building codes and the proper tools and experience to make sure your system is set up and configured correctly.

    Call Powerful Signal at 435-634-6800 or request a free custom quote online. We’ll design a custom system that will solve your cellular reception and connectivity problems at the best possible price point. We’ve designed thousands of cell signal amplifier systems—let us create one for you!

    Office floor with a cellular booster system and dome antenna An office floor with amplified cellular signal from a HiBoost amplifier and one dome antenna.

    Purchasing a HiBoost SLW Smart Link system

    The HiBoost SLW Smart Link can be self-installed if you are familiar with cellular amplification equipment. We’ll be happy to advise you on the best placement of antennas or provide a custom, turnkey solution. If you purchase this system as a standalone product, it includes the following components:

    HighBoost SLW Smart Link cell signal booster Pro25-5S-BTW icon HiBoost SLW Smart Link cell signal amplifier Pro25‑5S‑BTW
    HiBoost 12V/3A AC/DC power supply icon AC/DC adapter GM50‑120300‑F
    Top Signal omnidirectional building antenna TS210471 icon Choice of…
    Top Signal wideband outdoor omni antenna TS210471
    Top Signal 5G/4G Outdoor Pole-Mount Directional LPDA Antenna with N-Female Connector (50 Ohm) TS220971 icon …or
    Top Signal wideband outdoor LPDA antenna TS220971
    Top Signal TS-400 coax cable 75 feet TS340075 icon 75′ Top Signal TS‑400 coax cable TS340075
    Top Signal adjustable rooftop antenna mount TS430001 icon Adjustable rooftop antenna mount TS430001
    Top Signal 50-ohm lightning surge protector TS450001 icon Top Signal 50‑ohm lightning surge protector TS450001
    HiBoost SLW Smart Link user manual icon HiBoost SLW Smart Link user manual

    1-antenna systems also include:

    Top Signal EDGE Dual-Mount Dome Antenna N-Female TS250620 icon Choice of…
    Top Signal EDGE dome antenna w/mounting post, nut & mounting plate TS250620
    Top Signal EDGE Flex-Mount Panel Antenna N-Female TS260820 icon …or
    Top Signal EDGE panel antenna w/wall-mount bracket & mounting post TS250374
    Top Signal TS-400 coax cable 50 feet TS340050 icon 50′ Top Signal TS‑400 coax cable TS340050

    2-antenna systems also include:

    Top Signal EDGE Dual-Mount Dome Antenna N-Female TS250620 icon Choice of…
    Top Signal EDGE dome antenna w/mounting post, nut & mounting plate TS250620 (×2)
    Top Signal EDGE Flex-Mount Panel Antenna N-Female TS260820 icon …or
    Top Signal EDGE panel antenna w/wall-mount bracket & mounting post TS250374 (×2)
    Top Signal TS-400 coax cable 50 feet TS340050 icon 50′ Top Signal TS‑400 coax cable TS340050 (×2)
    Top Signal TS412101 2-Way Splitter 50 Ohm N-Female icon Top Signal 2‑way N‑female 50‑ohm splitter TS412101
    Top Signal TS-400 coax cable 2 feet TS340002 icon 2′ Top Signal TS‑400 coax jumper cable TS340002

    3-antenna systems also include:

    Top Signal EDGE Dual-Mount Dome Antenna N-Female TS250620 icon Choice of…
    Top Signal EDGE dome antenna w/mounting post, nut & mounting plate TS250620 (×3)
    Top Signal EDGE Flex-Mount Panel Antenna N-Female TS260820 icon …or
    Top Signal EDGE panel antenna w/wall-mount bracket & mounting post TS250374 (×3)
    Top Signal TS-400 coax cable 50 feet TS340050 icon 50′ Top Signal TS‑400 coax cable TS340050 (×3)
    Top Signal TS413101 3-Way Splitter 50 Ohm N-Female icon Top Signal 3-way 50-ohm splitter TS413101
    Top Signal TS-400 coax cable 2 feet TS340002 icon 2′ Top Signal TS‑400 coax jumper cable TS340002

    4-antenna systems also include:

    Top Signal EDGE Dual-Mount Dome Antenna N-Female TS250620 icon Choice of…
    Top Signal EDGE dome antenna w/mounting post, nut & mounting plate TS250620 (×4)
    Top Signal EDGE Flex-Mount Panel Antenna N-Female TS260820 icon …or
    Top Signal EDGE panel antenna w/wall-mount bracket & mounting post TS250374 (×4)
    Top Signal TS-400 coax cable 50 feet TS340050 icon 50′ Top Signal TS‑400 coax cable TS340050 (×4)
    Top Signal TS414101 4-Way Splitter 50 Ohm N-Female icon Top Signal 4-way 50-ohm splitter TS414101
    Top Signal TS-400 coax cable 2 feet TS340002 icon 2′ Top Signal TS‑400 coax jumper cable TS340002

    How the HiBoost SLW Smart Link works

    The HiBoost SLW Smart Link receives the outside cell signal, amplifies it, and rebroadcasts it inside your office or home through one to four ceiling-mounted dome antennas or a wall-mounted panel antennas. This allows you to stay connected in areas where cell service is poor or where your office’s building materials interfere with signals from the local cell tower.

    Works with all major cellular carriers

    The HiBoost SLW Smart Link works with all major wireless carriers, including Verizon, AT&T, T-Mobile, DISH Wireless, UScellular, GCI Alaska, and most others.

    It operates on common cellular frequencies.

    • 700 MHz (SMH) bands 12, 13, 17.
    • 850 MHz (Cellular 850) band 5.
    • 1700/2100 MHz (AWS) band 4.
    • 1900 MHz (PCS) bands 2, 25.
    Carrier logos for Verizon, AT&T, T-Mobile, UScellular, DISH Wireless, GCI Alaska
    T-Mobile customers please read about band 71 and cell signal boosters

    Which antennas should I choose?

    This system gives you the choice of an outdoor directional or omnidirectional antenna and up to four indoor dome or panel antennas. Here are some general guidelines for selecting the right antennas.

    Outside (donor) antenna:

    • The cylindrical omnidirectional antenna works best in most circumstances. The omni gathers signal from all carrier towers in all directions.
    • The wedge-shaped LPDA directional antenna works best if your building is in a remote location with one single, distant tower providing cell service for your area. The LPDA is also an excellent choice if there’s a powerful cell tower nearby but you need to bypass that tower in favor of a more distant one operated by your preferred carrier.

    Inside (broadcast) antenna:

    • The ceiling-mounted EDGE dome antenna works best in most circumstances. It broadcasts downward and all around in a shape similar to a donut or an inner tube. It usually gives more broad, even coverage than a wall-mounted panel antenna and is less noticeable than a panel antenna. Installing a dome antenna does, however, require that you have access above the ceiling to pull cable and mount the antenna.
    • The wall-mounted EDGE panel antenna broadcasts forward in a sideways teardrop shape. It’s a better option if you don’t have access above your ceiling or if you want to mount the antenna on the outside perimeter of the area you want to cover. It’s also a good option for long, narrow indoor areas.

    If you’re still not certain which antennas will work best for you, please call us at 435-634-6800. Our technical support representatives will be happy to discuss your specific requirements and give you a recommendation based on years of professional experience.

    How much area will the HiBoost SLW Smart Link cover?

    With strong outside cell signal (−95 dBm RSRP or greater), the HiBoost SLW can cover up to 35,000 square feet of indoor building space with 700 MHz signal. The size of the coverage area depends on many factors, including:

    • Outside cell signal strength received by the donor antenna.
    • The type of antennas you choose (dome or panel) and where you position them.
    • Inside building materials. (Cellular frequencies pass through wood framing and drywall more easily than through steel and concrete.)
    • Cellular frequencies used by the carrier and the device. (Lower-frequency LTE and 800 MHz signals travel farther than higher-frequency AWS and PCS signals.)

    Substandard or inadequate conditions in any of these factors will reduce your coverage area.

    Powerful Signal has years of experience designing and installing cellular amplification systems. Please call us at 435-634-6800 or contact us online, and we’ll be happy to calculate the coverage area this system will provide in your building and answer any other questions about this amplifier.

    FCC notice

    For information on federal rules governing the use of consumer cell signal boosters, please see our FCC notice page.

    Prop 65 notice

    Caution triangle icon Warning This product can expose you to chemicals, including nickel, which is known to the State of California to cause cancer, and Bisphenol A, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.govexternal link icon.

    Product Specifications

    Usage:
    Large office
    Strong outside signal (−95 dBm RSRP, 5 bars):
    Up to 35,000 ft² indoor coverage @ 700 MHz
    Fair outside signal (−105 dBm RSRP, 3 bars):
    Up to 20,000 ft² indoor coverage @ 700 MHz
    Weak outside signal (−115 dBm RSRP, 1 bar):
    Up to 3,000 ft² indoor coverage @ 700 MHz
    Outside antenna:
    Omnidirectional cylinder or directional LPDA
    Inside antenna:
    Omnidirectional dome or directional panel (1–4)
    Cable Type:
    400
    Connector Type:
    N
    Impedance:
    50 Ω
    Gain/Loss:
    +72 dB max
    Max Output Power (Uplink):
    24 dBm
    Max Output Power (Downlink):
    15 dBm
    Booster Case Material:
    Metal
    Signal Readout:
    Backlit LCD display with adjustable uplink, downlink & power by channel

    Warranty Information

    For warranty information on this product, please see our HiBoost warranty information page.
