weBoost Signal 4G 460119 M2M Booster

weBoost Signal 4G 470019 M2M Booster

weBoost Signal 4G 460119 M2M Booster


weBoost Signal 4G M2M inline cell signal booster. This 3G/4G booster improves transmission signal strength and data quality for vending machines, ATM's, monitoring equipment, remote video monitoring, etc. Complete kit with 4G booster, antenna and coax.
Price::
$249.99
Item Number:
460119



weBoost Signal 4G Description

The in-line weBoost Signal 4G 5-band M2M direct connect cell signal booster is designed to be connected to a 3G or 4G cellular device for M2M applications.  It is bidirectional and works on all US and Canadian CDMA/GSM networks that use 3G and 4G frequencies.

The compact weBoost Signal 4G allows for easy integration into M2M applications.  Integrators and OEMs can pair the weBoost Signal 4G with a variety of antennas.  Technology is incorporated into this device to handle site overload protection, and proximity detection to prevent interference on cellular networks.

M2M Machine-to-Machine data solutions with Wilson 811225 DataPro


Features

  • FCC and Canada Certified
  • For CDMA/GSM Networks
  • 3G and 4G bands supported
  • Bidirectional - boosts signal to and from cell sites
  • SMA-FeMale Connectors
  • Boosts signal for all US and Canadian cell carriers

Box Contents

  1. weBoost Signal 4G M2M Booster
  2. AC Power Supply
  3. 3' RG174 SMA Male to SMA Male jumper
  4. 4" Magnet Mount Antenna with SMA connector


weBoost Signal 4G Specifications

Part Number 460119
Type CDMA and GSM
Frequency
Band 17 700MHz
Band 13 700MHz
Band 5   850MHz
Band 4   1700/2100MHz
Band 25/2 1900MHz
Max Gain 15 dB
Power Required AC/DC 5V/2A
Connectors SMA Female
Dimensions
6.2 x 3.6 x 1.3 inch
15.7 x 9.1 x 3.3 cm
Weight
1.2 lbs
0.54 kg
FCC Notice This is a CONSUMER device.
BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider and have your provider's consent. Most wireless providers consent to the use of signal boosters. Some providers may not consent to the use of this device on their network. If you are unsure, contact your provider. You MUST operate this device with approved antennas and cables as specified by the manufacturer. Antennas MUST be installed at least 20 cm (8 inches) from any person. You MUST cease operating this device immediately if requested by the FCC or a licensed wireless service provider. WARNING. E911 location information may not be provided or may be inaccurate for calls served by using this device.

Please note, the four largest carriers - AT&T, T-Mobile, Verizon and Sprint - and more than 90 regional carriers have given blanket consent for use of all boosters certified to the new FCC standards.
