WilsonPro 70 Plus 463127 4G Building Cell Phone Booster (One Antenna)

WilsonPro 70 Plus 463127 4G Building Cell Phone Booster (One Antenna)


High Usage - 4G - 1 Panel Antenna
Price::
Call for Quote
Item Number:
463127
1 Interior Panel Antenna
Type: Building
Application: 4G, AWS, 2G/3G
Manufacturer Warranty: 3 Year

Wilson Electronics Pro 70 Plus - 4G Professional Grade Cell Phone Booster

The WilsonPro 70 Plus provides the maximum 4G performance power of any competing solution available on the market today.  Bring a strong 3G and 4G cell signal into your building.  Keep your business connected by eliminating dropped calls, missed emails and text messages.  Maximum downlink (interior broadcast) allows for more expansive indoor signal coverage area.

Extensive tests done by independent labs prove Wilson cell signal boosters provide an indoor coverage area up to 6 times larger than what is provided by competing boosters.  Wilson Electronics Pro series boosters out perform the competition by delivering:
  • Higher uplink (phone-to-tower) power for higher user capacity and greater calling range.
  • Higher downlink (tower-to phone) power for more expansive indoor coverage area.
  • Lower noise for cleaner voice and data signal
The WilsonPro 70 Plus Cell Phone Booster uses a built-in uplink and downlink power meter that graphically displays current signal readings of the major bands supported; Cellular, PCS, Verizon LTE, AT&T LTE, and AWS.  This meter provides the ability to assist with exterior donor antenna positioning by displaying signal strength as antennas are adjusted, thus helping to locate the best possible direction for directional antennas.


Why Powerful Signal

Powerful Signal is a full service supplier with direct relations with Wilson Electronics.  Below is what you can expect from Powerful Signal.
  • Full Service, sales, technical support, and warranty returns
  • System design for small or large systems
  • Product experience and knowledge
Powerful Signal has been working with Wilson Electronics and their products for 10 years.  We know the business and how to successfully support you.



Coverage Area

There are many factors that effect cell signal booster coverage in buildings.  Powerful Signal has many years of experience designing and installing building cell signal booster systems.  We won't promise you unrealistic coverage areas, but we will calculate and design a system which will meet your needs and performance expectations.

Major Features

Wilson Electronics is the industry leader in cell signal boosters.  Below are some of the major features of the WilsonPro 70 Plus.
  • Latest auto-adjustment technology for better system balancing
  • Best-in-class uplink and downlink power exceeding competitors specifications
  • Built-in signal meter to assist in exterior antenna positioning
  • Industry leading 3 year warranty

WilsonPro for Professional Installers

The WilsonPro series is designed for installation by professional installers.  The 463127 Cell Phone Booster Kit includes one of Wilson's most powerful 5-band cell signal boosters allowing you to cover larger areas in your building.  Powerful Signal provides professional design services to installers for this kit and other larger multi-antenna systems for even larger implementations.  We also have an extensive list of professional installers that work with us.

Contact Powerful Signal at 866-912-3444 for Professional Design Services and Installation

Works with All Major Carriers

The 5-band technology incorporated into the WilsonPro 70 Plus works with all major US and Canadian Carriers.  Both 3G, 4G, and XLTE are supported making this an excellent solution for all carriers.
  • AT&T
  • Verizon
  • T-Mobile
  • Sprint
  • US Cellular
  • All other major US and Canadian Carriers

 What is in the Box

  • WilsonPro 70 Plus 5-Band Cell Phone Booster
  • Wilson Wide-Band Panel Antenna
  • Wilson Wide-Band Directional Antenna
  • 60' 400 Coax Cable
  • 75' 400 Coax Cable
  • 2' 400 Coax Cable Jumper
  • Lightning Surge Protector

WilsonPro 70 Plus Cell Phone Booster (463127)

WilsonPro 70 Plus Booster (463127)

The WilsonPro 70 Plus is Wilson Electronics professional series cell signal booster.  This 5-band amplifier is best-in-class against the competition with maximum performance for commercial environments that require high throughput and heavy voice/data loads.

Wilson Interior Panel Antennas

Wilson Wide Band Panel Antenna

The panel antenna has a directional broadcast.  The Wilson panel antenna is wide-band and handles all frequencies of the WilsonPro 70 Plus booster.  The panel antenna can be placed on a wall facing across the room on laid above the ceiling sheet rock and pointed downwards.  The antenna will broadcast down through the ceiling sheet rock if you choose to mount the dome in the attic.

Wilson Exterior Directional Antenna

Wilson Wide Band Directional Antenna

A Wilson wide-band directional antenna is supplied with the WilsonPro 70 Plus kit.  This directional antenna connects easily to the 400 low loss coax.  The Wilson directional antenna needs to be pointed in the direction of the cell phone towers for best performance.  It comes with mounting hardware that allows it to be mounted to a 2" pole or a Universal J-Pipe mount.


Wilson 400 Coax Cable

High quality 400 low loss coax cable comes with the kit.  Each piece of coax cable is pre-cut and terminated with N-Male connectors that easily connect to the amplifier and antennas without any tools.  Two lengths of coax are supplied, one to run from the amplifier to the outside antenna, the other to run from the amplifier to the inside antenna.  Select the lengths that best fit your environment.

DO NOT coil coax.  It will cause performance problems with the system.





   WilsonPro 70 Plus Cell Phone Booster Specifications

Product Number 463127
Antenna Connectors N-Female
Antenna Impedance 50 Ohms
Max Gain 70dB
Weight 2.81 lbs / 1.27 kg
Dimensions 8.875 x 6.0 x 1.5 in / 22.5 x 15.2 x 3.8 cm
Frequency 698-746 MHz, 746-787 MHz, 824-894 MHz, 1850-1995 MHz, 1710-1755 / 2110-2155 MHz
Power Requirements AC/DC 12V / 3A
FCC Notice This is a CONSUMER device.
BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider and have your provider's consent. Most wireless providers consent to the use of signal boosters. Some providers may not consent to the use of this device on their network. If you are unsure, contact your provider. You MUST operate this device with approved antennas and cables as specified by the manufacturer. Antennas MUST be installed at least 20 cm (8 inches) from any person. You MUST cease operating this device immediately if requested by the FCC or a licensed wireless service provider. WARNING. E911 location information may not be provided or may be inaccurate for calls served by using this device.

Please note, the four largest carriers - AT&T, T-Mobile, Verizon and Sprint - and more than 90 regional carriers have given blanket consent for use of all boosters certified to the new FCC standards.
